1U Rackmount 19″ HDMI® LCD KVM Console

Model No.: LH1901

  • Hardware Structure: A short depth single rail rack console featuring a 19″ LCD monitor with an integrated keyboard and touchpad, fits for all standard 19″ equipment cabinet.
  • Space-saving & Simple Design: Easy to install and simple to operate. It slides neatly into a 1U rack space when not in use.
  • Standard HDMI Connection: Connect to a server or computer via standard HDMI connector
  • High Video Resolution: The 19in. LCD screen supports video resolutions up to 1280 x 1024@60Hz.
  • Flexible Viewing Angle: The LCD display module can be opened up to 108 degrees.
  • Easy to Use: This LCD KVM console allows users to control only one server or manage multiple servers by connecting a KVM switch.

Overview

Kinan’s LH1901 is a keyboard monitor mouse switch that integrated 19″ LCD monitor, full 99-key keyboard and touchpad in a 1U height of single rail housing. The included cable allows for connection to a USB computer or KVM. Features a 19-inch LCD TFT panel, the LH1901 supports high video quality up to 1280×1024@60Hz.

The LH1901 rackmount console comes with a single HDMI port, which can be connected directly to a server or PC, or to a KVM switch to control multiple systems. The usb monitor switch serves as the monitoring and managing console for standard KVM Switches.

Hardware Features

  • Integrated rackmount console drawer with 19” LCD rack mount monitor, keyboard/touchpad
  • Standard HDMI connection-Connect to a server or computer via standard HDMI connector
  • LCD module can be opened up to 108 degrees to provide a comfortable viewing angle
  • Support computers with USB keyboard and mouse
  • Internal power supply

Hardware Features

  • Integrated rackmount console drawer with 19” LCD rack mount monitor, keyboard/touchpad
  • Standard HDMI connection-Connect to a server or computer via standard HDMI connector
  • LCD module can be opened up to 108 degrees to provide a comfortable viewing angle
  • Support computers with USB keyboard and mouse
  • Internal power supply

High Resolution

  • 19” TFT rackmount keyboard monitor supports highlight, high definition and high resolution
  • Support input video resolutions up to 1280 x 1024 @60Hz

High Resolution

  • 19” TFT rackmount keyboard monitor supports highlight, high definition and high resolution
  • Support input video resolutions up to 1280 x 1024 @60Hz

High Performance Touchpad

  • Touchpad with scroll wheel – Eliminates the need for a separate, external mouse

High Performance Touchpad

  • Touchpad with scroll wheel – Eliminates the need for a separate, external mouse

Keyboard

  • Multi-language support–English, Russian, German, French, UK and Spanish, etc.
  • Full size 99 keys keyboard with integrated number pad

Keyboard

  • Multi-language support–English, Russian, German, French, UK and Spanish, etc.
  • Full size 99 keys keyboard with integrated number pad

Wide Compatibility

  • Multiplatform Support-Compatible with Windows, Sun, Unix and Linux
  • Supports servers form Lenovo, HUA WEI, HP, IBM, Cisco and Dell, etc.

Wide Compatibility

  • Multiplatform Support-Compatible with Windows, Sun, Unix and Linux
  • Supports servers form Lenovo, HUA WEI, HP, IBM, Cisco and Dell, etc.

Diagram

Connection Diagram LH1901-1

Specification

Model LH1901
Computer Connections Direct 1
Max 1
Port emulation Keyboard, mouse USB
LCD monitor LCD model SXGA TFT
View area 19 “
Optimum resolution 1280×1024@60Hz
Display color 16.7 M
Brightness 250cd/m²( T y p )
Contrast ratio 1000 : 1 ( T y p )
Pixel pitch(mm) 0.2928(H) × 0.2928(W)
Mouse X/Y resolution >1000 points / inch, (40 points/mm)
Scroll wheel Support scroll wheel function
Keyboard 99 keys (82 keys main keyboard+17 independent small numeric keyboard)
Input power 100V-240Vac, 50-60Hz, <1.5A
Power consumption 17W
Operating temperature 0 ─ 50 ℃
Store temperature -20 ─ 60 ℃
Humidity 0─80% RH, non-condensing
Net weight 12 kg
Product dimension (W × D × H) 448mm×505mm×42.5mm
Package dimension (W × D × H) 765mm×615mm×185mm

Package Contents

  • 1x LCD KVM Console (LH1901)
  • 1x Power Cord (Regional)
  • 1x Quick Start Guide
  • 2x Mounting Rails
  • 1x USB+HDMI KVM Cable (1.8m/6ft)
