19″ 16 Port CAT5 LCD KVM over IP Switch 1-Local / 2-Remote Access

Model No.: HT5916

Integrated KVM Console with 19″ LCD monitor
Control up to 16 servers simultaneously
High video resolution – resolution is up to 1920×1080@60Hz for remote console, local console resolution is up to 1280 x 1024@60Hz
Dual power supply
Remote Access – support 1 local user and 2 remote users
Support servers with VGA/DVI/HDMI/DP port

Get A Free Quote

Features

Diagram

Specification

Accessory

Download

Overview

Featuring an integrated LCD monitor, keyboard, and touchpad in a 1U rack-mountable housing, the HT5916 LCD KVM over IP Switch is a control unit that allows secure access to 16 computers from a single KVM console. The HT5916 features IP-based connectivity that allows local and remote operators to monitor and access the computers. With TCP/IP communications protocol, it can be accessed from any computer on the LAN, WAN or Internet.

It’s easy to install the HT5916, just plug the cable properly without software, complicated installation procedures, and compatibility issues. And then connect computers with compact RJ-45 connectors and Cat 5e/6 cable. The transmitting distance is up to 100m.

Hardware Features

19” LCD monitor KVM console
Keyboard/touchpad in a 1U height console
Standard Cat5 connection
LCD module can be opened up to 108 degrees to provide a comfortable viewing angle
External console port – provides an external VGA, keyboard and mouse port to manage the LCD KVM Switch from an external console
One bus for IP KVM remote access
Dual power supply

Hardware Features

19” LCD monitor KVM console
Keyboard/touchpad in a 1U height console
Standard Cat5 connection
LCD module can be opened up to 108 degrees to provide a comfortable viewing angle
External console port – provides an external VGA, keyboard and mouse port to manage the LCD KVM Switch from an external console
One bus for IP KVM remote access
Dual power supply

Local Console

Control up to 16 computers
Support 1 local user & 2 remote users
Multiple switching methods – UI interface, hotkeys and pushbuttons
Support servers with VGA/DVI/HDMI/DP port
Wide compatibility – Windows, Linux, Unix, Mac, Solaris (Sun), Redhat, Ubuntu
Support mouse synchronization mode-automatically synchronizes the local and remote mouse movements
Video synchronization with local console – EDID information for local console display can be stored in the host module for video resolution optimization
Hot pluggable–add or remove computers without having to power down the switch
The supported resolution of local console is up to 1280 x 1024@60Hz

Local Console

Control up to 16 computers
Support 1 local user & 2 remote users
Multiple switching methods – UI interface, hotkeys and pushbuttons
Support servers with VGA/DVI/HDMI/DP port
Wide compatibility – Windows, Linux, Unix, Mac, Solaris (Sun), Redhat, Ubuntu
Support mouse synchronization mode-automatically synchronizes the local and remote mouse movements
Video synchronization with local console – EDID information for local console display can be stored in the host module for video resolution optimization
Hot pluggable–add or remove computers without having to power down the switch
The supported resolution of local console is up to 1280 x 1024@60Hz

Remote Console

Adaptive 10 / 100 / 1000 Mbps network
WEB browser-based remote management
Resolution for remote console is up to 1920×1080@60Hz
BIOS-level access
Video quality and video tolerance can be adjusted to optimize data transfer speed, data transfer speed is up to 30 FPS
Full screen or scalable video display
Remote users and local users can control the same server/computer synchronously
Support AES / DES / 3DES encryption
Support audit function-allows the administrator to audit the device through the system log and operation log
Exit Macros support
Configurable user and group permissions for server access and control

Remote Console

Adaptive 10 / 100 / 1000 Mbps network
WEB browser-based remote management
Resolution for remote console is up to 1920×1080@60Hz
BIOS-level access
Video quality and video tolerance can be adjusted to optimize data transfer speed, data transfer speed is up to 30 FPS
Full screen or scalable video display
Remote users and local users can control the same server/computer synchronously
Support AES / DES / 3DES encryption
Support audit function-allows the administrator to audit the device through the system log and operation log
Exit Macros support
Configurable user and group permissions for server access and control

Diagram

Specification

Model		HT5916
Computer Connections	Direct	16
	Max	16
Port Selection	Keyboard, Mouse	Button, UI, Web, Hotkey
LCD Monitor	Model	SXGA TFT
	View Area	19″
	Optimum Resolution	1280×1024@60Hz
	Color	16.7 M
	Brightness	250 cd/m²
	Contrast Ratio	1000:01:00
	Pixel Pitch(mm)	0.2928(H) × 0.2928(W)
Mouse	X/Y Resolution	>1000 points / inch, (40 points/mm)
	Scroll Wheel	Supports Scroll Wheel function
Keyboard		99 keys (82 keyboard + 17 number pad)
Remote	Remote Control	KVM Control (ActiveX)
	Management	Web
	Security	DES Encrypted
	Resolution	1920×1080@60Hz
Power Input		100V- 240Vac, 50-60Hz, <1.5A
Power Consumption		29W
Operating Temperature		0 — 50 ℃
Store Temperature		-20 —60 ℃
Humidity		0~80% RH, non-condensing
Net Weight		13.4kg
Product Dimension (W × D × H)		448mm × 605mm × 42.5mm
Package Dimension (W × D × H)		765mm × 615mm × 185mm
