Background

The China Academy of Railway Sciences is the only multi-disciplinary and multi-professional comprehensive research institution of China Railway. It mainly develops, produces and sells large-scale infrastructure testing equipment and information systems in the field of railway and urban rail transit, and provides related testing equipment, technical services and overall solutions for infrastructure maintenance and repair.

Requirements

The comprehensive track inspection vehicle is a special vehicle used to detect the geometric state and irregularity of the track. It is an important tool to ensure the safety, stability and comfort of driving and a guide for track maintenance and repair. The main operation management system in the vehicle is mainly composed of five functional modules, real-time data acquisition of track detection, real-time image processing, positioning point data collection, geomagnetic data processing, and pantograph network video collection.

To save relevant manpower and material resources, the customer urgently needs a complete set of KVM management systems and keyboard-mouse switches, which can find the location of poor track by collecting real-time data, graphics, positioning points, routes, etc., so as to repair or limit the speed of the vehicle, and determine the mileage section that should be planned for maintenance, and prepare a maintenance operation plan.

Solution

Kinan HT1216 switch is designed with advanced Cat5 cable as a means of transmission. It supports USB ports and can be controlled by hotkeys and OSD menu. What’s more, this switch can support cascading mode and the transmission distance of high-quality video signals is up to 50m. With the function of identity authentication and password protection for timeout, the users can safely access to HT1216 which is hot-pluggable to achieve uninterrupted exchange and use.

Features

• Provide up to 16 RJ45 ports and Cat5/5E/6 cables.
• Provide 5 channels to the local users and 4 RJ45 ports that can be connected to 5 users.
• Support USB keyboard and mouse, VGA display ports, PS/2 ports, and mixed plugging.
• The OSD menu with the function of naming the server, setting the scanning time, and setting the password can be used easily via a keyboard.
• Support simultaneous power-on and hot-plugging with isolation and simulation techniques.
• High-quality video. The automatic signal compensation function ensures a distance of up to 50m between the control and the computer, providing sufficient bandwidth for the display output without distorting the image.
• When switching to a different server, the keyboard and mouse status of the original server can be automatically stored and restored when switching back.
• Built-in memory for storing system settings.
• Support cross-server environments such as Windows, Linux, Unix, Max, and Sun, etc.
• The video resolution of the local computers is up to 1920 X 1080 @ 60Hz.

KM-1302 is a USB keyboard-mouse switch, allowing users to switch servers seamlessly by hotkeys or sliding mouse to different screens. 2 servers can be managed simultaneously via a set of keyboard and mouse and many types of systems can be supported. With this switch, users can enjoy a smooth experience.

Features

• No need to install driver.
• Manage 2 computers simultaneously.
• Keyboard-mouse switch.
• Support a wide range of computer systems.
• No external power supply is required.
• Easy to use with an integration of wire and device.
• Double-click the middle mouse button to lock or dismiss the slide function.

Result

With the help of Kinan HT1216 KVM over IP switch, the client can collect real-time data, real-time images, and positioning point data to take some urgent measures, locate the mileage section that needs to be maintained and create a maintenance operation plan.
